Solar Power Module S4875G6S4875G6
Introdcution
The S4875G6 is a high-efficiency DC/DC conversion module. It supports a wide DC voltage input from conventional photovoltaic modules (85
Vdc to 435 Vdc). It defaults to 53.5 Vdc output, adjustable via the power monitoring module. The module supports overcurrent protection, output overvoltage protection, and overtemperature protection. It is equipped with fan cooling and provides front-to-back airflow.
Features
Maximum output power: 4000 W, supports hot-swapping
Modular design: Compatible with Huawei power insertion frame and 75 A rectifier module slot
Supports voltage regulation and current limiting functions
Maximum Power Point Tracking (MPPT) for string
Built-in fan: Fan speed depends on internal temperature
lComplies with IEC/EN62109-1 standards
Meets RoHS requirements, CE certified
Applications
For areas with sufficient sunlight and no/poor grid power
Hybrid scenarios
Off-grid scenarios
Specifications
