Smart Magic Box
-
High-density Embedded Power Supply ETP48600-C5A3ETP48600-C5A3
Product Presentation
The ETP48600-C5A3 is a novel embedded power supply developed by Huawei, featuring an innovative architecture with compact dimensions and high power density (up to 36 kW capacity at 5U height). Its input/output interfaces support modular configuration as required. The device offers convenient installation and maintenance, full digitalization, and intelligent capabilities, making it suitable for scenarios such as expansion and renovation of existing wireless sites, deployment of 3G/4G and 5G wireless networks, as well as emerging 5G-enabled applications like C-RAN/MEC.
Product Features
l 36 kW@5U, compact size with high power density
l Innovative architectural design supports multiple energy inputs (solar, grid power, or diesel generator) and various output standards (AC: 220 V; DC: 12/24/36/48/57 V), catering to diverse operational scenarios.
l Equipped with a smart power distribution unit that supports multi-level power shutdown management and is compatible with diversified 5G service networks.
l The Huawei-accompanied Li lithium battery supports a-57VDC constant voltage output, meeting the high-power AAU remote power supply requirements for 5G applications.
l Intelligent peak shaving with site exemption from utility power retrofit: When peak load exceeds the utility input power, the power system controls battery discharge, enabling coordinated supply from both utility and battery to eliminate peak loads on the grid and reduce investment required for utility capacity expansion.
l Intelligent peak shifting releases the potential of power stations: the power grid makes adaptive adjustments to make full use of the price difference between peak and valley electricity,reducing the electricity costs of power stations
l Intelligent management and remote online maintenance reduce the number of station visits and lower maintenance costs.
