HUAWEI Rectifier Module R4850G2R4850G2
Brief Introduction
The R4850G2 is a high-power-density, high-efficiency digital rectifier module that converts 85V AC to 300V AC inputs into a rated 53.5V DC output with up to 96% efficiency. It features high power density, soft start capability, hot-swappable design, comprehensive input and output protection, and low noise performance.Equipped with cutting-edge power monitoring technology, it enables real-time monitoring of both the rectifier module and load while allowing backend adjustment of output voltage.
Chara Cteristic
l With an efficiency of up to 96%, it offers exceptional energy savings.
l The input voltage range is wide, from 85 V AC to 300 V AC.
l Working temperature range: -40°C to +75°C
l Total Harmonic Distortion (THD) ≤5%
l Supports online hot-swapping
l Fully digital control
l Support for smart meters
l Supports CAN co- mmunication
l Support LED display ala- rms
l Supports voltage and current adjustment as well as current sharing functionality
l Complies with RoHS requirements
l Obtained TUV, CE, and UL certifications, along with the CB certificate.
